Ace Anodizing provides a wide range of coating services, including type II bright dip anodizing. This project consisted of anodizing a variety of parts in various colors, all of which had to meet specific criteria for color and quality.

We developed a process of calibrated color ranges and an effective way to blend draw lines in extruded parts while maintaining a consistent appearance. This highly cosmetic application required consistent color ranges across all components, and was sealed to allow periodic cleaning without degradation to the color and coating. By using a combination of processes not normally used together we were able to obtain the desired results and eliminate a labor intensive mechanical finishing step. This project consisted of lot sizes ranging from 500 to 2,500, and was produced in five days.

For more information on this project, or to learn how Ace Anodizing can service your powder coating needs, see the table below or contact us directly.



Request a Quote/Information

Highlights of this Custom Bright Dipped Anodizing Project

Product Description Type II bright dip anodizing on extrusions & screw machined parts.
Custom Bright Dipped Anodizing Capabilities Applied/Processes Primary:
Type II Bright Dip Anodizing
  • Rack
  • Clean
  • Etch
  • Bright Dip
  • Chemical Polish
  • Type II Anodize
  • Dye/Color
  • Seal and Package
Secondary:
Thickness Testing
Packaging
  • Custom Packaging w/ Protective Barriers
  • Cell Divided Containers
  • Layer Pack Larger Components
Overall Part Dimensions Various Sizes
Material Anodized 6000 Series Aluminum
Finish Various Colors Including
  • Blue
  • Green
  • Gold
  • Purple
  • Black
  • Red
Resistances Application Requiring Consistent Color Ranges Across All Components
Sealed to Allow Cleaning
Features
  • Blend Draw Lines in Extruded Parts
  • Client Required a Lister to the Machined Components
  • Eliminate a Labor
Industry for Use Commercial
Industrial
Recreational
In process testing/inspection performed Visual Inspection
Coating Weight
Seal Quality
Salt Spray Testing
Volume Several Components in Lot Sizes of 500 to 2,500
Delivery/Turnaround Time 5 Days
Delivery Location Minnesota
Standards Met AA-M12 C31 A33
MIL-8625F Type II Class II
ISO 9001:2008
215 R5
Project Name Anodizing of Various Extruded and Screw Machined Components
